| Categories | Tubular Linear Actuators |
|---|---|
| Brand Name: | Linsheng Auto II MaxM |
| Model Number: | LS-INLA-1 |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | negotiable |
| Price: | 29-299 USD/PCS |
| Payment Terms: | L/C, T/T, PayPal |
| Supply Ability: | 10000 PCS per month |
| Delivery Time: | 7 Days |
| Packaging Details: | Paper gift box, 20PCS/Carton |
| Name: | 12v actuators for sale |
| Voltage Related: | 12V/ 24V DC |
| IP rating: | Up to IP69K |
| Standard stroke: | 20~1000mm |
| Minimum installation dimension: | Stroke+289mm |
| Color: | Black or Grey |
| Warranty: | 1 Year |
| Customization: | Available |
LS-INLA-1 up to IP69K protection ensures it will with stand high temperature, high pressure water jets,
and the ingress of dust and other solid contaminants
| Linear Actuator | LS-INLA-1 |
| Voltage of motor | 12V DC or 24V DC |
| Maximum load | 4,500N (push); 3,000N (pull) |
| Maximum speed at full load | 24.0mm/s (with 500N in a push or pull condition) |
| Standard stroke | 20~1000mm |
| Minimum installation dimension | Stroke+289mm |
| IP rating | Up to IP69K |
| Color | Black or grey |
| Operational temperature range | -5°C~+65°C |
| Operational temperature range | +5°C~+45°C (at Full performance) |
| Storage temperature range | -40°C~+70°C |
