Name: 10A05 THRU 10A10 High Current Rectifier Silicon Rectifier Diode
Brand: Hua Xuan Yang
Price: 1 USD

Home > Transformers >

10A05 THRU 10A10 High Current Rectifier , Silicon Rectifier Diode

Categories	High Voltage Rectifier Diode
Place of Origin:	ShenZhen China
Brand Name:	Hua Xuan Yang
Certification:	RoHS、SGS
MOQ:	1000-2000 PCS
Price:	Negotiated
Packaging Details:	Boxed
Delivery Time:	1 - 2 Weeks
Payment Terms:	L/C T/T Western Union
Supply Ability:	18,000,000PCS / Per Day
Model Number:	10A05 THRU 10A10
Type:	General Purpose Silicon Rectifier
RθJA:	20.0℃/W
IFSM:	600Amp
VF:	1.0Volts
Product ID:	10A05 THRU 10A10
I(AV):	10.0Amps

Contact Now

Add to Cart

10A05 THRU 10A10 Reverse Voltage - 50 to 1000 Volts Forward Current - 10.0 Ampere

FEATURES

Low reverse leakage
High forward surge current capability
High temperature soldering guaranteed:250 C/10 seconds,0.375”(9.5mm) lead length,5 lbs. (2.3kg) tension

MECHANICALDATA

Case:JEDEC DO-41 molded plastic body

Terminals:Plated axial leads,solderable per MIL-STD-750,

Method2026

Polarity:Color band denotes cathode end

Mounting Position:Any

Weight:0.072ounce,2.05grams

MAXI MUMRATINGS AND ELECTRICAL CHARACTERISTICS

Note:

1. Measured at 1MHz and applied reverse voltage of 4.0VD.C.

2. Thermal resistance from junction to ambientat 0.375(9.5mm) lead length,P.C.B.mounted

RATINGS AND CHARACTERISTIC CURVES 1N5400 THRU 1N5408
