| Categories | Programmable IC Chip |
|---|---|
| Brand Name: | Xilinx |
| Model Number: | XC6SLX9-2TQG144C |
| Certification: | ROHS |
| Place of Origin: | Original Factory |
| MOQ: | 10pcs |
| Price: | Negotiate |
| Payment Terms: | T/T, Western Union，Paypal |
| Supply Ability: | 100000pcs |
| Delivery Time: | 1-3Days |
| Packaging Details: | BOX |
| Series: | Embedded Processors and Controllers |
| name: | Programmable IC chip |
| Package: | TQFP144 |
Technical Specifications
Physical | |
| Case/Package | TQFP |
| Contact Plating | Tin |
| Mount | Surface Mount |
| Number of Pins | 144 |
Technical | |
| Max Operating Temperature | 85 °C |
| Max Supply Voltage | 1.26 V |
| Min Operating Temperature | 0 °C |
| Min Supply Voltage | 1.14 V |
| Number of I/Os | 102 |
| Number of Logic Blocks (LABs) | 1430 |
| Number of Logic Elements/Cells | 9152 |
| Number of Macrocells | 9152 |
| Number of Registers | 11440 |
| Operating Supply Voltage | 1.2 V |
| RAM Size | 72 kB |
| Speed Grade | 2 |
Dimensions | |
| Height | 1.45 mm |
| Length | 20 mm |
| Width | 20 mm |
Compliance | |
| REACH SVHC | Unknown |
| RoHS | Compliant |
Spartan-6 FPGA Electrical Characteristics
Spartan®-6 LX FPGAs are available in -3, -3N, -2, and -1L speed grades, with -3 having the highest performance. Spartan-6 LXT FPGAs are available in -3, -3N, and -2 speed grades, with -3 having the highest performance. Spartan-6 FPGA DC and AC characteristics are specified for both commercial and industrial grades. Except the operating temperature range or unless otherwise noted, all the DC and AC electrical parameters are the same for a particular speed grade (that is, the timing characteristics of a -2 speed grade industrial device are the same as for a -2 speed grade commercial device). However, only selected speed grades and/or devices might be available in the industrial range. The Spartan-6 FPGA -3N speed grade designates devices that do not support MCB functionality
|
